MAXBELT Conveyor Belts
For those who demand durability and safety in order to obtain the lowest cost per ton transported.

Composed of high strength and quality fabrics, our belts are covered with Rubber Covers designed to offer durability and safety in accordance with national (NBR) and international (DIN, ISO, ASTM, ARPM and ABNT) regulations.

Learn more about our Belts and Covers
  • Polyester/nylon (MB) and/or nylon/nylon (MBN) fabric housings that preserve the adhesion between layers, increasing fatigue resistance and preventing breakage and stretching.
  • Our belts undergo special treatment with the presence of pre-tensioning that maximizes their resistance while maintaining their flexibility and stability.
  • Excellent shock absorption with low elongation rate even under high stresses.
  • Reinforced edges, excellent lodging, and mildew and moisture resistance.
  • Laminated or coated belts with several options of Rubber Covers, which enable the alliance between safety and the best operational cost-benefit.
  • Discover our High-Performance Solutions composed of high-performance belts, breakers and wear indicator.

FOR®

Cover presenting the necessary qualities for the transportation of fertilizers, highly resistant to oils. It presents anti-static and self-extinguishing properties and withstands temperatures up to 248ºF. It meets ISO 340 (ASTM D 378-13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity.

GRÃO®

Compound specially developed for the transportation of grains, bran pellets and others, presenting self-extinguishing and anti-static properties in its composition, suitable for use in silos, warehouses and port corridors. Its composition allows it to work at temperatures up to 194ºF, complying with ISO 340 (ASTM D 378-13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity.

GRÃO-EXTREME®

A cover that combines anti-static and self-extinguishing flame properties in order to meet ISO 340 standards (ASTM D 378 13.2 flame test / MSHA 30 CFR Part 18) and ISO 284 for electrical conductivity, maintaining the advantages of the traditional GRÃO® cover, associated with a maximum abrasion loss of 0.00305in³, GRÃO EXTREME® is the ideal solution for applications in Port Terminals.

GRÃO-SUPREME®

Top quality cover for extreme transportation conditions of bran, soybean meal, grains, DDG and DDGS with oil percentage up to 20%, in addition to resistance to the action of acid and alkaline products, such as insecticides and pesticides. It has good abrasion resistance and withstands temperatures up to 248ºF. It meets ISO 340 (ASTM D 378-13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity.

HD®

Compound developed to resist abrasion, cuts and bad weather, it is a great option for severe activities and for activities with rough edged or sharp materials, such as: iron ore, quartz, granite, limestone, basalt, gravel, manganese, petroleum coke, slag, etc. The HD® compound is recommended for materials reaching peak temperatures up to 194°F and complies with DIN W (0.00549 in³).

HD-MINERAÇÃO®

Cover specially developed to meet large mining companies and their strictest specifications. Product aimed at offering high resistance to impacts, cuts and abrasion, even facing heavy mining. With maximum abrasion loss of 0.00427 in³, it exceeds by more than 20% DIN W standard requirements. HD-MINERAÇÃO® is designed to operate with temperature peaks up to 194°F.

HDS®

Excellent performance compound designed to meet severe and high-impact operations, preventing tears. HDS® cover was developed to extend belt’s service life, thereby reducing the need for replacement. HDS® is recommended for materials reaching peak temperatures up to 194ºF with excellent abrasion resistance not exceeding 0.00305 in³ of maximum wear and tear.

HDS-EXTREME®

Cover designed for extremely severe and high impact applications, providing greater resistance to cuts and ripping and tearing. HDS-EXTREME® is recommended for materials reaching temperature spikes up to 176ºF and has extreme resistance to abrasion, not exceeding 0.00183 in³.

HDS-IMPACT®

Composed of the qualities found in HDS® product line, this cover was specially  developed to withstand the rigors of applications in primary crushers, in which abrasiveness, cuts, tears and strong impact are found. This cover was designed to overcome the maximum abrasion resistance defined by standard DIN W (0.00305 in³).

HDS-MINA®

Featuring all HDS cover advantages, such as maximum abrasion of 0.00305 in³, excellent performance on severe high impact applications and or high risk of tear; this cover combines anti-static and self-extinguishing flame properties in order to meet ISO 340 (ASTM D 378-13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity, making HDS MINA® ideal for underground mines.

HDS-MINERAÇÃO®

This compound brings the technical quality of the HDS® family covers, offering excellent performance in severe and high impact applications, combining anti-static and self-extinguishing flame properties that meet ISO 340 standards (ASTM D 378 13.2 flame test / MSHA 30 CFR Part 18) and ISO 284 for electrical conductivity. HDS-MINERAÇÃO® stands out for the high performance in this segment, as it combines operational safety with a maximum abrasion loss of 0.00305in³.

HDS-W®

Cover developed to withstand high impacts and cuts. It has superior performance on conveyors with extremely severe application, such as those in which there is high impact and in the transportation of logs that reach the belt in unfavorable conditions. It can operate at temperature spikes up to 194ºF and meets the standard ARPM 2, (0.01068 in³).

HOR®

Product developed to offer excellent resistance in the transportation of products with high presence of mineral and vegetable oils, urea and other elements with severe acidity conditions. Cover with good abrasion resistance and suitable for the transportation of materials with temperatures up to 248ºF, being recommended for metal parts bathed in oil, soybean meal, animal or vegetable fats, compost, fertilizers in general and insecticides.

HOR-SUPREME®

This compound presents the same characteristics as HOR®, that is, it has excellent resistance in the transportation of products with high presence of mineral and vegetable oils with severe acidity conditions, has good abrasion resistance and withstands temperatures up 347°F. Cover designed for the transportation of green cake, soybean meal and others.

LD®

Resistant and durable in highly abrasive applications; subject to cuts and to ripping and tearing, as well as in severe working conditions where HD® cover is not needed. It maintains good flexibility at low temperatures. Recommended for materials such as sand, gravel, coal, cement, phosphate, sulfur, salt, limestone, talc, cereal grains, wood, lime, etc. Suitable for materials reaching temperature peaks up to 176ºF. Abrasion level DIN X (0.00732 in³), and ARPM I.

LD-MINA®

Resistant and durable cover with good flexibility at low temperatures, designed to meet medium abrasion applications. It was designed for underground mining, in which anti-static and self-extinguishing properties are required. Recommended for materials reaching temperature peaks up to 176ºF. It meets the abrasion category level DIN X (0.00732 in³), ISO 340 (ASTM D 378-13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity.

LD-REAÇÃO®

Cover developed for application in the fertilizer industry promoting greater resistance amid chemical reaction processes and chemical attacks. It also offers excellent abrasion resistance and can be used in processes up to 248°F.

ORANGE®

Cover designed to meet the needs of citrus transportation, especially oranges. This compound offers protection against acids from fruit peels, before those fruits are squeezed, and withstands temperatures up to 248ºF.

ORANGE HT®

Specially developed for the transport of citrus derivatives. Its composition offers high resistance to the action of the element D’limonene, with temperatures reaching up to 248°F with peaks up to 284°F.

PINNUS®

Compound developed to provide excellent resistance to abrasion and cuts. This cover also stands out for being designed to prevent contamination and deterioration that may be caused by resins that exist in pine wood splinters and chips.

RO®

Compound developed with moderate resistance in order to meet applications with oil (animal/vegetable) impregnation, slightly acids or basics. It is a great option for cotton seed transportation. This product is recommended for applications with temperatures up to 194ºF.

SBK®

Cover designed to meet transportation in port terminals and corridors, withstanding temperatures up to 176ºF. It has good abrasion resistance (0.00732 in³) and meets ISO 340 (ASTM D 378- 13.2 flame test standard/ MSHA 30CFR Part 18) and ISO 284 on electrical conductivity.

SH-EPDM®

The highlight of this cover is to be specially designed to offer maximum resistance to abrasive materials, as well as resistance to high temperatures, which can be applied in activities that reach up to 399.2°F. It is often used in the transportation of materials such as clinker, sinter, iron pellets, foundry sand, etc.

NOTE: For SH-EPDM® compound, the following minimum top cover thicknesses are recommended for maximum service life:

  • Material temperature up to 320ºF – 1/4”
  • Material temperature from 321.8ºF to 356ºF – 5/16”
  • Material temperature from 357.8ºF to 399.2ºF – 3/8”

SHT®

Cover specially designed to avoid cracking or hardening that can be caused by thin and hot abrasive materials. This compound also has high heat resistance and can be applied to convey materials with temperatures up to 302ºF. It is ideal for products such as ashes, industrial carbon, petroleum coke, slag, foundry sand, clinker, cement and cast metals.

SHT-SUPER®

This cover presents the same qualities and characteristics as the model, SHT® that is, it was designed to offer greater heat resistance and to withstand temperatures up to 302ºF, without showing cracks or hardening during its application. Moreover, its composition allows a superior performance in relation to abrasion resistance.

NOTE: For SHT® and SHT-SUPER®compounds, the following minimum top cover thicknesses are recommended for maximum service life:

  • Material temperature up to 194ºF – 3/16”
  • Material temperature from 195.8ºF to 230ºF – 1/4”
  • Material temperature from 231.8ºF to 266ºF – 5/16”
  • Material temperature from 267.8ºF to 302ºF – 3/8”

The best solutions come when we share our knowledge

Belt wear can vary greatly depending on the operational characteristics of each production or logistics process, such as:

  • The wear level of applications
  • Type of transport operation
  • Physicochemical characteristics of the transported product
  • Stresses acting on the conveyor belt and others.

Contact our team and find the best solution for your operational profile.
